Ploughs
Mouldboard Plough (Normal)-PARS
The primary soil tillage machine is mounted from tractor's hydraulic lifting unit and universal three point linkage system. Therefore transportation to the field can be easily done.The purposes of tillage are as follows; cultivating of stubbly and fallowing soil, mulching the soil, preparing the seed bed, controlling the weeds and diseases, putting the fertilizer, herbicide and stubble in the soil, decreasing the wind and water erosion, increasing infiltration and leaving the rainwater on the field.Ploughs are manufactured as 2, 3, 4, 5 and 6 moldboard, 85x25mm, 85×28 mm and 90×30 mm diameter sheet frame chassis. Distances between moldboards are; 60 cm, 85 cm and. shall work together with 9,10,12,14 and 16 inch tractor power. By means of safety system of our ploughs, being damaged rate is reduced at the lowest level.
TECHNICAL SPECIFICATIONS
| Technical Specifications* | Unit | PARS 102 | PARS 112 | PARS 122 | PARS 132 | PARS 142 | PARS 162 |
| Number of Bodies | pcs | 2 | 2 | 2 | 2 | 2 | 2 |
| Total Length (L) | mm | 1590 | 1590 | 1765 | 1765 | 1820 | 2150 |
| ft.in. | 5'3" | 5'3" | 5'10" | 5'10" | 5'12" | 7'1" | |
| Total Width (W) | mm | 950 | 965 | 1040 | 1040 | 1100 | 1150 |
| ft.in | 3'1" | 3'2" | 3'5" | 3'5" | 3'7" | 3'9" | |
| Total Height (H) | mm | 1250 | 1250 | 1275 | 1275 | 1275 | 1300 |
| ft.in | 4'1" | 4'1" | 4'2" | 4'2" | 4'2" | 4'3" | |
| Height (H1) | mm | 650 | 650 | 670 | 670 | 670 | 700 |
| ft.in | 2'2" | 2'2" | 2'3" | 2'3" | 2'3" | 2'4" | |
| Working Depth (Max.) | mm | 200-230 | 230-260 | 260-300 | 260-300 | 300-350 | 350-400 |
| ft.in. | 8"-9" | 9"-10" | 10"-12" | 10"-12" | 12"-14" | 14"-16" | |
| Working Width (L1) | mm | 550 | 580 | 620 | 640 | 700 | 750 |
| ft.in. | 1'10" | 1'11" | 2' | 2'1" | 2'4" | 2'6" | |
| Space Between Bodies | mm | 275 | 290 | 310 | 320 | 350 | 375 |
| ft.in. | 10" | 11" | 12" | 13" | 14" | 15" | |
| Chassis Size | mm | 80x25 | 85x25 | 85x25 | 85x28 | 85x28 | 90x30 |
| ft.in. | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 4"x1" | |
| Required Power | hp | 40-50 | 40-50 | 55-60 | 55-60 | 60-65 | 70-80 |
| Weight | kg | 160 | 170 | 200 | 200 | 220 | 280 |
| Ibs | 352 | 374 | 440 | 440 | 485 | 617 |
| Technical Specifications* | Unit | PARS 93 | PARS 103 | PARS 113 | PARS 123 | PARS 133 | PARS 143 | PARS 163 |
| Number of Bodies | pcs | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Total Length (L) | mm | 2085 | 2195 | 2195 | 2480 | 2480 | 2560 | 2930 |
| ft.in. | 8'8" | 9'2" | 9'2" | 10'6" | 10'6" | 10'10" | 10'10" | |
| Total Width (W) | mm | 960 | 1085 | 1100 | 1175 | 1190 | 1235 | 1270 |
| ft.in | 4' | 4'4" | 4'6" | 4'10" | 5' | 5'3" | 5'3" | |
| Total Height (H) | mm | 1175 | 1250 | 1250 | 1275 | 1275 | 1275 | 1275 |
| ft.in | 3'10" | 4'1" | 4'1" | 4'2" | 4'2" | 4'2" | 4'2" | |
| Height (H1) | mm | 600 | 650 | 650 | 670 | 670 | 670 | 700 |
| ft.in | 1'12" | 2'2" | 2'2" | 2'3" | 2'3" | 2'3" | 2'4" | |
| Working Depth (Max.) | mm | 180-210 | 200-230 | 230-260 | 260-300 | 260-300 | 300-350 | 350-400 |
| ft.in. | 7"-8" | 8"-9" | 9"-10" | 10"-12" | 10"-12" | 12"-14" | 14"-16 | |
| Working Width (L1) | mm | 1060 | 1100 | 1160 | 1240 | 1280 | 1400 | 1400 |
| ft.in. | 3'6" | 3'7" | 3'10" | 4'9" | 4'2" | 4'7" | 4'7" | |
| Space Between Bodies | mm | 265 | 275 | 290 | 310 | 320 | 350 | 350 |
| ft.in. | 10" | 11" | 11" | 12" | 13" | 14" | 14" | |
| Chassis Size | mm | 80x25 | 85x25 | 85x25 | 85x28 | 85x28 | 85x28 | 85x28 |
| ft.in. | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | |
| Required Power | hp | 60-65 | 65-70 | 75-80 | 80-85 | 80-85 | 85-90 | 85-90 |
| Weight | kg | 330 | 410 | 450 | 470 | 470 | 490 | 490 |
| Ibs | 727 | 903 | 992 | 1036 | 1036 | 1080 | 1080 |
| Technical Specifications* | Unit | PARS 94 | PARS 104 | PARS 114 | PARS 124 | PARS 134 | PARS 144 |
| Number of Bodies | pcs | 4 | 4 | 4 | 4 | 4 | 4 |
| Total Length (L) | mm | 2645 | 2800 | 2800 | 3195 | 3195 | 3295 |
| ft.in. | 8'8" | 9'2" | 9'2" | 10'6" | 10'6" | 10'10" | |
| Total Width (W) | mm | 1225 | 1310 | 1365 | 1480 | 1535 | 1600 |
| ft.in | 4' | 4'4" | 4'6" | 4'10" | 5' | 5'3" | |
| Total Height (H) | mm | 1175 | 1250 | 1250 | 1275 | 1275 | 1275 |
| ft.in | 3'10" | 4'1" | 4'1" | 4'2" | 4'2" | 4'2" | |
| Height (H1) | mm | 600 | 650 | 650 | 670 | 670 | 670 |
| ft.in | 1'12" | 2'2" | 2'2" | 2'3" | 2'3" | 2'3" | |
| Working Depth (Max.) | mm | 180-210 | 200-230 | 230-260 | 260-300 | 260-300 | 300-350 |
| ft.in. | 7"-8" | 8"-9" | 9"-10" | 10"-12" | 10"-12" | 12"-14" | |
| Working Width (L1) | mm | 1060 | 1100 | 1160 | 1240 | 1280 | 1400 |
| ft.in. | 3'6" | 3'7" | 3'10" | 4'9" | 4'2" | 4'7" | |
| Space Between Bodies | mm | 265 | 275 | 290 | 310 | 320 | 350 |
| ft.in. | 10" | 11" | 11" | 12" | 13" | 14" | |
| Chassis Size | mm | 80x25 | 85x25 | 85x25 | 85x28 | 85x28 | 85x28 |
| ft.in. | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | |
| Required Power | hp | 60-65 | 65-70 | 75-80 | 80-85 | 80-85 | 85-90 |
| Weight | kg | 330 | 410 | 450 | 470 | 470 | 490 |
| Ibs | 727 | 903 | 992 | 1036 | 1036 | 1080 |
| Technical Specifications* | Unit | PARS 95 | PARS 105 | PARS 115 | PARS 125 | PARS 135 | PARS 145 |
| Number of Bodies | pcs | 5 | 5 | 5 | 5 | 5 | 5 |
| Total Length (L) | mm | 3205 | 3405 | 3405 | 3910 | 3910 | 4030 |
| ft.in. | 10'6" | 11'2" | 11'2" | 12'10" | 12'10" | 13'3" | |
| Total Width (W) | mm | 1490 | 1575 | 1670 | 1785 | 1880 | 1965 |
| ft.in | 4'11" | 5'2" | 5'6" | 5'10" | 6'2" | 6'5" | |
| Total Height (H) | mm | 1175 | 1250 | 1250 | 1275 | 1275 | 1275 |
| ft.in | 3'10" | 4'1" | 4'1" | 4'2" | 4'2" | 4'2" | |
| Height (H1) | mm | 600 | 650 | 650 | 670 | 670 | 670 |
| ft.in | 1'12" | 2'2" | 2'2" | 2'3" | 2'3" | 2'3" | |
| Working Depth (Max.) | mm | 180-210 | 200-230 | 230-260 | 260-300 | 260-300 | 300-350 |
| ft.in. | 7"-8" | 8"-9" | 9"-10" | 10"-12" | 10"-12" | 12"-14" | |
| Working Width (L1) | mm | 1325 | 1375 | 1450 | 1550 | 1600 | 1750 |
| ft.in. | 4'4" | 4'4" | 4'9" | 5'1" | 5'3" | 5'9" | |
| Space Between Bodies | mm | 265 | 275 | 290 | 310 | 320 | 350 |
| ft.in. | 10" | 11" | 11" | 12" | 13" | 14" | |
| Chassis Size | mm | 80x25 | 85x25 | 85x25 | 85x28 | 85x28 | 85x28 |
| ft.in. | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | 3"x1" | |
| Required Power | hp | 60-65 | 70-80 | 80-85 | 85-95 | 85-95 | 100-120 |
| Weight | kg | 430 | 510 | 550 | 590 | 590 | 610 |
| Ibs | 947 | 1124 | 1212 | 1300 | 1300 | 1344 |
